| Model | GE-F256-BC-2-A3 | |
|---|---|---|
| Cell Type | LiFePO₄ | |
| Module Capcity (Ah) | 314 | |
| Module Nominal Voltage (Vdc) | 51.2 | |
| Module Energy(kWh) | 16.08 | |
| Module Qty In Series | 16 | |
| System Nominal Energy(kWh) | 257.23 | |
| System Usable Energy (kWh) | 257.23 | |
| System Nominal Voltage (Vdc) | 8192 | |
| System Operating Voltage(Vdc) | 640~934.4 | |
| Rated DC Power (kW) | 129 | |
| Charge/Discharge Current(A) |
Recommend | 157 |
| Max.Continuous | 180 | |
| Peak discharge @15s/20~45℃ |
285 | |
| Other Parameters | ||
| Fire Protection System | Aerosol and Water fire interface,CO gas detection,Active exhaust and Explosion venting | |
| Cooling Method | SmartAir Cooling | |
| Communication Port | CAN,RS485 | |
| Communication protocol | CAN2.0,Modbus485 | |
| Operating Temperaturel （℃) | -30~55 | |
| Recommend Storage Temperaturel（℃) | 0-35 | |
| Humidity | 5%~95%RH (No Condensing) | |
| Altitude | 3000m | |
| IP Protection | IP55 | |
| Anti Corrosion Level | Standard:C4-M,customizable up to C5 | |
| Dimension(WxDxH,mm) | 1303x1240×2510 | |
| Weight(kg) | 2770 | |
| Installation Location | Floor mount | |
| Cycle Life | ≥8000(25±2℃,0.5P,EOL70%) | |
| Warranty | 10 years | |
| Certification | UN38.3,CEJEC62619,E62477,IEC62933-5-2,UL9540A | |
