| Model | GE-F120-4H2 | GE-F120-3H2 | GE-F120-2H2 |
| Nominal Output Power / UPS Power (W) | 30000 | 40000 | 50000 |
| AC Output Frequency and Voltage | 50 / 60Hz; 220 / 380, 230 / 400Vac | ||
| Grid Type | 3L / N / PE | ||
| Number of Parallel (Off-grid) | 10 | ||
| Energy Configuration (kWh) | 122.8 | ||
| Dimension (W × D × H, mm) | 1780 × 1056 × 2235 | ||
| Weight Approximate (kg) | 2090 | ||
| AC Output Rated Current (A) | 45 | 60 | 75.8 |
| Battery Operating Voltage (V) | 500 ~ 700 | ||
| Max. RTE | 89% | ||
| Battery Chemistry | LiFePO₄ | ||
| IP Rating of Enclosure | IP55 | ||
| Installation Method | Floor-Mounted | ||
| Storage Temperature (°C) | 0 ~ 35 | ||
| Operating Temperature (°C) | -20 ~ 55 (>43 derating) | ||
| Warranty | 10 years | ||
